This Flameproof cum Weatherproof Double Compression Cable Gland is suitable for upto Metric Threads M20/M25/M32/M40/M50, assembled with Armoured Cable with respect of cable (OD & UAD) dia size. Cable gland available in brass / aluminum / stainless steel material construction. The Cable Gland is suitable for used in Zone 1 & 2, Hazardous area gas group IIB.
| Order Code | METRIC | Order Code | METRIC |
|---|---|---|---|
| 020 | M 20 | 040 | M 40 |
| 025 | M 25 | 050 | M 50 |
| 032 | M 32 |
| Entry Size B.S.C | Equivalent Entry Size | Cable O/D | U/A Dia.D | Cable Sizes | ||
|---|---|---|---|---|---|---|
| Entry Size Metric | BSP/NPT | PG | ||||
| 3/4" | M20 X 1.5 | 1/2" | 11 to 13.5 | 12.5 to 16.0 | 6 to 10 | |
| 3/4" | M20 X 1.5 | 1/2" | 11 to 13.5 | 12.5 to 18.0 | 7.5 to 11.5 | 2Cx2.5, 2Cx4, 3Cx1.5 |
| 3/4" | M20 X 1.5 | 1/2" | 11 to 13.5 | 18.5 to 19.5 | 10 to 13.5 | 3Cx4, 3Cx6, 3Cx2.5, 2Cx6, 4Cx4 |
| 1" | M25 X 1.5 | 3/4" | 16 | 20 to 22 | 13.5 to 17 | 3Cx10, 4Cx10, 4Cx6 |
| 1" | M25 X 1.5 | 3/4" | 16 | 22.5 to 25.5 | 16.5 to 20 | 3Cx25, 3Cx35, 3Cx16, 4Cx16 |
| 1 - 1/2" | M40 X 1.5 | 1 - 1/4" | 29 | 26 to 29 | 21 to 24 | 3Cx50, 3.5Cx35, 4Cx25, 4Cx35, 3.5x25 |
| 1 - 1/4" | M32 X 1.5 | 1" | 21 | 26 to 29 | 21 to 24 | 3Cx50, 3.5Cx35, 4Cx25, 4Cx35, 3.5x25 |
| 1 - 1/2" | M40 X 1.5 | 1 - 1/4" | 29 | 29.5 to 33.5 | 24 to 28 | 3Cx70, 3.5Cx50, 4Cx50 |
| 1 - 1/2" | M40 X 1.5 | 1 - 1/4" | - | 34 to 37 | 28 to 30.5 | 3Cx95, 3.5Cx70 |
| 2" | M50 X 2.0 | 1 - 3/4" | - | 37.5 to 40.5 | 31 to 35 | 3Cx120, 3.5Cx95 |
| 2" | M50 X 2.0 | 1 - 3/4" | - | 41 to 45 | 34 to 37 | 3Cx150, 3.5Cx120 |
| 2" | M50 X 2.0 | 1 - 3/4" | - | 45.5 to 51 | 40 to 43 | 3Cx185, 3.5Cx150 |
